Product Overview:
Genuine CCEC Cummins 3419234 aftercooler assembly for NTA855 series engines. Cools intake air to boost power, improve fuel efficiency and extend engine life. 100% pressure tested, direct bolt-on installation. Fits 200-400kW generator sets and industrial equipment. Cummins global warranty included.
Key Features:
✅ Genuine CCEC : Made in Cummins Chongqing factory to exact specs for perfect fit
✅ Superior Cooling: 120-fin aluminum core delivers 15% better efficiency than aftermarket
✅ Extreme Durability: Cast iron end tanks resist corrosion/vibration; 10,000+ hours rated
✅ Plug-and-Play: Pre-assembled with gaskets/hardware; no modifications needed
✅ Rigorous Testing: 100% pressure tested at 150psi (1.5x working pressure) for zero leaks
✅ Emissions Compliant: Meets EPA Tier 2 and EU Stage II standar
Specification Table:
| Parameter | Details |
|---|---|
| Part Number | 3419234 |
| Brand | Genuine CCEC Cummins |
| Product Type | Complete Aftercooler Assembly (Air-to-Air) |
| Core Material | High-grade aluminum alloy (fin-and-tube) |
| End Tank Material | Ductile cast iron |
| Overall Dimensions | 1060mm × 420mm × 460mm (L×W×H) |
| Gross Weight | 30.5kg |
| Net Weight | 28.2kg |
| Working Pressure | 100psi (6.9bar) |
| Test Pressure | 150psi (10.3bar) |
| Cooling Capacity | 25kW |
| Inlet/Outlet Diameter | 76mm (3") |
| Mounting Holes | 8×M10 bolt holes |
| Primary Applications | 200-400kW diesel generator sets, construction machinery, mining equipment, oilfield rigs |
Why Choose Us?
✅100% Genuine Parts: Directly supplied by CCEC with official certification
✅Wholesale Discounts: Tiered pricing for bulk orders and long-term cooperation
✅Professional Support: Free technical guidance from certified engineers
✅Fast Global Delivery: 24h dispatch, worldwide shipping in 3-15days
